Measurement modes

Imaging

Q six specifications icon_Screenshot

Screenshot

Q six specifications icon_UnrolledFOV

Unrolled FOV

Q six specifications icon_UnrolledSection

Unrolled section

3D Modes

icon_SurfaceTopography

Surface topography

icon_SurfaceRoughness

Surface roughness

icon_CoatingThickness

Coating thickness

Inspection capabilities

Outer Surface

Outer surface

Inner Surface

Inner surface

Lateral Surface

Lateral surface

Edges

Edges

Measurable stent

Stent types Metallic, color coated, polymer, welded, with grooves and braided
OD 1 – 32 mm
Length Up to 200mm

Light sources

Flexible illumination Up to 9 light sources available
Standard illumination TOP white light, BACK green light and two SIDE white lights

Dimensions

Q vix specifications dimensions
Q vix specifications side dimensions

Sensorhead & Controller

Objectives performance

Imaging Objectives
MAG 2X 5X 10X
Numerical Aperture 0.055 0.14 0.28
Working Distance (mm) 34 34 34
Horizontal FOV (mm) 9 3.6 1.8
Spatial sampling (µm)[1] 4.4 1.76 0.88
Optical resolution (µm)[2] 2.77 1.09 0.54
Unrolled acquisition rate (mm2/s)[3] 120 20

1 Pixel size on the imaged surface.   2 L&S: Line and Space (500nm wavelength)
3 Frame rate 3000 fps.

3D Objectives
MAG 10XDI 20XDI 50XDI
Numerical Aperture 0.3 0.4 0.55
Working Distance (mm) 7.4 4.7 3.4
Horizontal FOV (mm) 1.8 0.9 0.36
Spatial sampling (µm)[1] 0.88 0.44 0.18
Optical resolution (µm)[2] 0.51 0.38 0.28
Vertical resolution (nm)[4] 1 1 1

1 Pixel size on the imaged surface.   2 L&S: Line and Space (500nm wavelength)
 4 Vibration isolation table is required.

Computer & Operating System

Computer HP Z220 SFF, HP display 2560×1440 pixels
Computer Dimensions (WxDxH) 338x381x100 mm
Monitor Dimensions (WxDxH) 614x218x534 mm (with stand)
Operating System Windows 10, 64 bits

Data management

Q vix specifications Data management scheme

Depending on the intended use, the Q six can be operated in three different environments: Development, Quality Assurance (QA) and Production. Each environment has its own databases.
Data is organized in three different categories:
1
System Databases containing User data and System configuration files
2
Stent Inspection Databases containing Stent Model data, Defect libraries and Acquisition, Analysis and Report recipes
3
Inspection Results

icon_GreenLight

530nm

icon_WhiteLight

550nm
